#Problem Description:
Good day.
Can anyone please assist me with my settings. i have tried the wiki but could not get it right. i can pick up my high site. The owner of the high site says he can see im connected but i cannot connect to the form or TT.
if there is anything that i missed can someone please assist me. i would much appreciate it.
also i was previously connected but moved. if there is anything else that i need to add i will do so. hope this thread is in the right category.
Thank you
#Your details:
WiND Node: dean900 #14681
PC IP:172.18.42.25
RB IP:172.18.42.30
#WUG-Check Script output
Download and run wug-check.bat and post the output below between the backticks below:
--------------
Start!
--------------
2017/11/09
02:40 PM
--------------
----------
systeminfo
----------
Host Name: DESKTOP-UISE6HV
OS Name: Microsoft Windows 10 Pro
OS Version: 10.0.15063 N/A Build 15063
OS Manufacturer: Microsoft Corporation
OS Configuration: Standalone Workstation
OS Build Type: Multiprocessor Free
Registered Owner: Reaper
Registered Organization:
Product ID: 00331-10000-00001-AA957
Original Install Date: 2017/05/13, 9:56:01 AM
System Boot Time: 2017/11/08, 2:41:42 PM
System Manufacturer: Gigabyte Technology Co., Ltd.
System Model: B250M-D3H
System Type: x64-based PC
Processor(s): 1 Processor(s) Installed.
[01]: Intel64 Family 6 Model 158 Stepping 9 GenuineIntel ~3500 Mhz
BIOS Version: American Megatrends Inc. F2, 2016/11/25
Windows Directory: C:\WINDOWS
System Directory: C:\WINDOWS\system32
Boot Device: \Device\HarddiskVolume1
System Locale: en-za;English (South Africa)
Input Locale: en-us;English (United States)
Time Zone: (UTC+02:00) Harare, Pretoria
Total Physical Memory: 8ÿ152 MB
Available Physical Memory: 5ÿ786 MB
Virtual Memory: Max Size: 9ÿ432 MB
Virtual Memory: Available: 6ÿ528 MB
Virtual Memory: In Use: 2ÿ904 MB
Page File Location(s): C:\pagefile.sys
Domain: WORKGROUP
Logon Server: \\DESKTOP-UISE6HV
Hotfix(s): 3 Hotfix(s) Installed.
[01]: KB4022405
[02]: KB4049179
[03]: KB4041676
Network Card(s): 1 NIC(s) Installed.
[01]: Intel(R) Ethernet Connection (2) I219-V
Connection Name: Ethernet
DHCP Enabled: No
IP address(es)
[01]: 172.18.42.25
[02]: fe80::d0c:9d0e:42bc:12e0
Hyper-V Requirements: VM Monitor Mode Extensions: Yes
Virtualization Enabled In Firmware: Yes
Second Level Address Translation: Yes
Data Execution Prevention Available: Yes
--------
ipconfig
--------
Windows IP Configuration
Ethernet adapter Ethernet:
Connection-specific DNS Suffix . :
Link-local IPv6 Address . . . . . : fe80::d0c:9d0e:42bc:12e0%12
IPv4 Address. . . . . . . . . . . : 172.18.42.25
Subnet Mask . . . . . . . . . . . : 255.255.255.248
Default Gateway . . . . . . . . . : 172.18.42.30
------
arp -a
------
Interface: 172.18.42.25 --- 0xc
Internet Address Physical Address Type
172.18.42.30 00-0c-42-e0-3a-38 dynamic
172.18.42.31 ff-ff-ff-ff-ff-ff static
224.0.0.22 01-00-5e-00-00-16 static
224.0.0.251 01-00-5e-00-00-fb static
224.0.0.252 01-00-5e-00-00-fc static
239.255.255.250 01-00-5e-7f-ff-fa static
--------------
route -4 print
--------------
===========================================================================
Interface List
12...1c 1b 0d a9 55 31 ......Intel(R) Ethernet Connection (2) I219-V
1...........................Software Loopback Interface 1
===========================================================================
IPv4 Route Table
===========================================================================
Active Routes:
Network Destination Netmask Gateway Interface Metric
0.0.0.0 0.0.0.0 172.18.42.30 172.18.42.25 291
127.0.0.0 255.0.0.0 On-link 127.0.0.1 331
127.0.0.1 255.255.255.255 On-link 127.0.0.1 331
127.255.255.255 255.255.255.255 On-link 127.0.0.1 331
172.18.42.24 255.255.255.248 On-link 172.18.42.25 291
172.18.42.25 255.255.255.255 On-link 172.18.42.25 291
172.18.42.31 255.255.255.255 On-link 172.18.42.25 291
224.0.0.0 240.0.0.0 On-link 127.0.0.1 331
224.0.0.0 240.0.0.0 On-link 172.18.42.25 291
255.255.255.255 255.255.255.255 On-link 127.0.0.1 331
255.255.255.255 255.255.255.255 On-link 172.18.42.25 291
===========================================================================
Persistent Routes:
Network Address Netmask Gateway Address Metric
172.16.0.0 255.240.0.0 172.18.42.30 1
0.0.0.0 0.0.0.0 172.18.42.30 Default
===========================================================================
--------------------------
nslookup wind.ctwug.za.net
--------------------------
*** Request to UnKnown timed-out
DNS request timed out.
timeout was 2 seconds.
Server: UnKnown
Address: 172.18.1.1
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
-------------------------------------
nslookup wind.ctwug.za.net 172.18.1.1
-------------------------------------
*** Request to UnKnown timed-out
DNS request timed out.
timeout was 2 seconds.
Server: UnKnown
Address: 172.18.1.1
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
----------------------------------
nslookup wind.ctwug.za.net 8.8.8.8
----------------------------------
*** Request to UnKnown timed-out
DNS request timed out.
timeout was 2 seconds.
Server: UnKnown
Address: 8.8.8.8
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
DNS request timed out.
timeout was 2 seconds.
--------------------------
tracert -d -w 1000 8.8.8.8
--------------------------
Tracing route to 8.8.8.8 over a maximum of 30 hops
1 172.18.42.30 reports: Destination net unreachable.
Trace complete.
-----------------------------
tracert -d -w 1000 172.18.1.1
-----------------------------
Tracing route to 172.18.1.1 over a maximum of 30 hops
1 <1 ms <1 ms <1 ms 172.18.42.30
2 4 ms 3 ms 3 ms 172.18.43.250
3 * * * Request timed out.
4 * * * Request timed out.
5 * * * Request timed out.
6 * * * Request timed out.
7 * * * Request timed out.
8 * * * Request timed out.
9 * * * Request timed out.
10 * * * Request timed out.
11 * * * Request timed out.
12 * * * Request timed out.
13 * * * Request timed out.
14 * * * Request timed out.
15 * * * Request timed out.
16 * * * Request timed out.
17 * * * Request timed out.
18 * * * Request timed out.
19 * * * Request timed out.
20 * * * Request timed out.
21 * * * Request timed out.
22 * * * Request timed out.
23 * * * Request timed out.
24 * * * Request timed out.
25 * * * Request timed out.
26 * * * Request timed out.
27 * * * Request timed out.
28 * * * Request timed out.
29 * * * Request timed out.
30 * * * Request timed out.
Trace complete.
------------------------------
tracert -d -w 1000 172.18.1.11
------------------------------
Tracing route to 172.18.1.11 over a maximum of 30 hops
1 <1 ms <1 ms <1 ms 172.18.42.30
2 13 ms 5 ms 5 ms 172.18.43.250
3 * * * Request timed out.
4 * * * Request timed out.
5 * * * Request timed out.
6 * * * Request timed out.
7 * * * Request timed out.
8 * * * Request timed out.
9 * * * Request timed out.
10 * * * Request timed out.
11 * * * Request timed out.
12 * * * Request timed out.
13 * * * Request timed out.
14 * * * Request timed out.
15 * * * Request timed out.
16 * * * Request timed out.
17 * * * Request timed out.
18 * * * Request timed out.
19 * * * Request timed out.
20 * * * Request timed out.
21 * * * Request timed out.
22 * * * Request timed out.
23 * * * Request timed out.
24 * * * Request timed out.
25 * * * Request timed out.
26 * * * Request timed out.
27 * * * Request timed out.
28 * * * Request timed out.
29 * * * Request timed out.
30 * * * Request timed out.
Trace complete.
--------------------------------
tracert -d -w 1000 172.26.66.132
--------------------------------
Tracing route to 172.26.66.132 over a maximum of 30 hops
1 <1 ms <1 ms <1 ms 172.18.42.30
2 6 ms 2 ms 6 ms 172.18.43.250
3 * * * Request timed out.
4 * * * Request timed out.
5 * * * Request timed out.
6 * * * Request timed out.
7 * * * Request timed out.
8 * * * Request timed out.
9 * * * Request timed out.
10 * * * Request timed out.
11 * * * Request timed out.
12 * * * Request timed out.
13 * * * Request timed out.
14 * * * Request timed out.
15 * * * Request timed out.
16 * * * Request timed out.
17 * * * Request timed out.
18 * * * Request timed out.
19 * * * Request timed out.
20 * * * Request timed out.
21 * * * Request timed out.
22 * * * Request timed out.
23 * * * Request timed out.
24 * * * Request timed out.
25 * * * Request timed out.
26 * * * Request timed out.
27 * * * Request timed out.
28 * * * Request timed out.
29 * * * Request timed out.
30 * * * Request timed out.
Trace complete.
---------------
Done!
---------------
2017/11/09
02:45 PM
---------------
