Is CTWUG out of IP Ranges

From my understading ctwug is out of 172.26 ip ranges.

I was allocated few Ranges for following areas:

DeaneTowers: Malibu Area (172.26.138.0)
Leda : Main HS (172.26.139.0)
Blackhawk: Rustdal (172.26.140.0)
Blackheath/Eersteriver (172.26.141.0) made it half for each area

Recently i gave away one half of 172.26.141 range to Uberlegen.

Issue i am now sitting with is Blackheath HS is finally completed but i do not have IP Range for the area and currently area is sitting with 8x clients and growing fast.

My question is what do i do now? If any advice can be given will be helpfull as currently sitting with complete HS with no IP Range

Dizzle and Gekido manages the ips for your area, the whole delft/belhar/bluedowns/eersteriver area is bursting out of the seems.

2 Likes

Thank You :pray: i will speak to them if they have solutions as i have an idea on what to do but hopefully they have a better idea :bulb:

@LeeDeane could you kindly send me the details of the HS.
If the HS has currently an IP range, but it’s exhausted.
How many clients are currently connected?
Is the site running OSPF?
I will allocate a range for you.

@LeeDeane could you PM me, my phone is not working. Or you can send me a message on CTWUG Chat

Thought the messages was taking long to go through

My apologies. Everything seem to break at once.

no worries I send you a PM

No we are not, we are just trying to manage it better.

CTWUG has been allocated two /16 ranges which gives us 131070 ips.
Most people are allocated /29 which is 8 ips, off course some sites use /30(4ips) for mikrotik ospf links and /29 for ubnt ospf links. So lets just say for argument sake that all clients has a /28 range this will then cover all the ospf links anyways.

131070 divided by /28(16 ips) then we will have enough ips for 8192 clients. We are currently under 2000 clients. This should tell you that CWTUG has ample ips left and we must just manage it better.

1 Like

Your area has been allocated 12284 ips if we divide this to see how many /29 can get into it we get 1536 possible clients. Excluding for all the ospf links you will another chunk of that range.

2 Likes

Thank you @Ogon. @dizzle is ontop of his game as always :heart_eyes:

3 Likes
